ebm-papst M4Q045 ebm-papst 62W Fan Motor for use with ebm-papst Q Series
ebm-papst M4Q045 ebm-papst 62W Fan Motor for use with ebm-papst Q Series
500 in stock
Vendor: Skyward Telecom
Collapsible row
Collapsible row
Our Services
- Cost-effective equipment
- Faster delivery
- Worldwide shipping
- Alternative supply
- Sample service
- Test and warranty
Product Overview
1. Core Technical Parameters (62W Standard Version)
| Parameter Item | 230V 50Hz Model | 115V 60Hz Model |
|---|---|---|
| Series Name | M4Q045 Square Shaded-Pole Motor | M4Q045 Square Shaded-Pole Motor |
| Rated Input Power | 62 W | 62 W |
| Nominal Voltage | 230 VAC | 115 VAC |
| Frequency | 50 Hz | 60 Hz |
| Max Rated Speed | 1550 rpm | 1550 rpm |
| Rated Current | 0.31 A | 0.61 A |
| Output Torque | 24 N·cm | 20 N·cm |
| Bearing Type | Calotte Sleeve Bearing | Calotte Sleeve Bearing |
| Protection Class | IP42 | IP42 |
| Insulation Class | Class B | Class B |
| Continuous Ambient Temp | -30 ℃ ~ +40 ℃ | -30 ℃ ~ +40 ℃ |
| Storage & Transport Temp | -40 ℃ ~ +80 ℃ | -40 ℃ ~ +80 ℃ |
| Net Weight | Approx. 2.3 kg | Approx. 2.3 kg |
| Standard Cable | 3-core jacketed cable (0.5 mm²) with brass terminals | 3-core jacketed cable (0.5 mm²) with brass terminals |
2. Mechanical & Structural Specifications
- Housing: Integral die-cast aluminum square shell, excellent heat dissipation & anti-corrosion performance
- Rotation Direction: Counter-clockwise (CCW) viewed towards the rotor shaft
- Mounting Standard: 71.4 mm bolt circle with 3×M4 threaded mounting holes; dual mounting centerline options (18 mm / 26 mm)
- Shaft Structure: Standard output shaft with plastic impeller hub fixing flange for quick blade assembly
- Drainage: No condensation drain holes; sealed bearing shield design
- Operation Duty: S1 continuous 24-hour running mode
- Installation Freedom: Supports horizontal or vertical shaft mounting positions
3. Electrical & Safety Protection Features
- Built-in Thermal Overload Protector (TOP): Automatically cuts off power when overheated, auto-resets after cooling to avoid motor burnout caused by stall or blocked impeller
- Safety Touch Current: ≤ 0.75 mA, complies with IEC 60990 safety standard
- Protection Class I: Requires customer connection of protective earth terminal
- EMC Compliance: Meets EN 60335 household & refrigeration equipment electromagnetic standards
- Low starting current & stable torque output for low-speed refrigeration fan operation
4. Certifications & Compliance
- Global Approvals: VDE, CE, UL, CCC, EAC
- Standard Conformity: EN 60335-1 household appliance safety standard
- RoHS compliant, free of restricted hazardous substances
5. Key Product Advantages
- Compact square all-aluminum structure, small footprint for narrow refrigeration compartment installation
- Built-in thermal cut-off protection, no extra external safety circuit required
- Wide operating temperature range down to -30°C, stable performance in cold storage, freezer and low-temperature refrigeration environments
- Standardized mounting hole layout, highly interchangeable to replace old refrigeration fan motors of mainstream brands
- Low-noise sleeve bearing design with service life over 20,000 hours under normal refrigeration working conditions
- Dual voltage variants (115V / 230V) to fit European, Asian and North American refrigeration equipment markets
6. Typical Application Scenarios
Product Technical Introduction
We specialize in supplying a full range of industrial and commercial cooling fans, including Axial fans, Centrifugal fans, Tangential blowers, Blowers, Air condition fans, Data center fans, and ICT fans. These fans are widely used in HVAC systems, air conditioning units, data centers, industrial automation equipment, telecom base stations, and power cabinets.
3 Tiered Sourcing Solutions for Differentiated Engineering Budgets
- 100% New Original OEM Units: Authentic genuine brand blowers with complete factory datasheets, original EC drive modules, full parameter consistency, and official brand performance warranties, suitable for high-reliability long-cycle industrial projects.
- High-Performance Compatible Equivalent Fans: Professionally engineered cross-brand replacement blowers with fully matched outline dimensions, static pressure, air volume, operating voltage, rotational speed, and noise indicators. Significantly lower procurement cost while maintaining equivalent operational stability for mass standardized equipment.
- Tested Refurbished / Second-Hand Units: Disassembled deep cleaning, bearing replacement, circuit board inspection, and full bench performance calibration. Cost-efficient solution for budget-sensitive maintenance & retrofit projects without sacrificing continuous operating stability.
Core Technical Advantages for Industrial Engineering Projects
✅ Full Technical Category Coverage
Complete cooling portfolio ranging from miniature DC compact fans to heavy-duty industrial axial & centrifugal blowers, covering all mainstream airflow pressure and size specifications for cabinet thermal dissipation.
✅ Harsh Climate Adaptation for African Markets
All cooling units pass high-temperature continuous operation & dust resistance aging tests, optimized for tropical high-heat, high-dust outdoor industrial & telecom site operating conditions.
✅ Customized Technical Modification Support
Customizable frame size, input voltage (AC110/230V / DC24/48V), speed regulation modules, IP waterproof casing, and wiring harness configurations per customer engineering drawings.
✅ Strict Full-Link Performance Calibration
Every blower undergoes independent bench testing for air volume, static pressure, operational noise, EC drive efficiency, long-hour continuous stability before warehouse delivery; test reports available upon request.
✅ Standardized Global After-Sales Technical Support
12-month comprehensive warranty for all supplied units. Free technical troubleshooting, replacement & exchange services for quality defects under rated normal operating conditions.
About Skyward Telecom
Founded in 2009, Skyward Telecom (Skywardtel) is a professional industrial thermal management supplier rooted in Guangdong, China. We adhere to integrity-driven technical service as our core operation principle, dedicated to resolving procurement difficulties for equipment engineers and manufacturing enterprises seeking stable, cost-effective telecom & industrial cooling ventilation hardware.
For over 15 years, we have delivered standardized customized cooling solutions to engineering clients across more than 80 global countries, accumulating industry-wide recognition for our professional technical matching capability and end-to-end supply chain service.
Technical FAQ
1. Who is Skyward Telecom?
We are a China-based industrial cooling fan technical supplier established in 2009, focusing on full-series EC/AC ventilation equipment global supply. Our core market distribution breakdown:
• Africa Market: 50.00% (primary target for tropical harsh-condition telecom & industrial cooling)
• European Market: 15.00%
• Middle East Market: 10.00%
• Southeast Asia Market: 5.00%
• North & South American Market: 20.00%
Our internal team consists of 80–100 staff, including dedicated thermal engineering technicians providing exclusive technical matching support for emerging tropical markets.
2. How do we guarantee fan technical performance & quality consistency?
- Pre-production prototype sample testing & parameter confirmation available prior to mass order bulk manufacturing;
- 100% bench testing of airflow, static pressure, noise level, EC drive efficiency and long-run stability before shipment;
- Deep cleaning, circuit inspection and mechanical calibration for all original, compatible and refurbished fan units;
- Only units passing multi-index QC calibration will be labeled, packed and arranged for global logistics delivery.
3. Full Range of Industrial Cooling Equipment We Supply
We provide full thermal dissipation hardware solutions covering all mainstream industrial ventilation types:
- Axial Fans: Miniature DC compact cooling fans & large industrial AxiForce axial blowers (200/250/300mm frame size)
- Centrifugal Fans: EC/AC forward & backward curved centrifugal blowers for HVAC & heavy industrial equipment
- Tangential Cross-Flow Blowers: Dedicated cross-flow fans for commercial air conditioning & ventilation systems
- High-Pressure Industrial Blowers: Boost blowers for heating boilers, industrial drying & ventilation equipment
- Air Condition Special Fans: Custom blowers for commercial & industrial integrated air conditioning units
- Data Center Cooling Fans: High-efficiency low-energy fans for server racks, cabinet thermal management systems
- ICT Telecom Fans: Specialized cooling blowers for outdoor base stations, network switches & communication power cabinets
New original, performance-matched compatible equivalents and fully calibrated refurbished units are available for nearly all mainstream fan brands & model specifications.
4. Why choose our cooling fans over competing suppliers?
- One-stop full technical portfolio: All mainstream industrial cooling fan types are stocked, eliminating the need for multi-supplier sourcing for your thermal projects;
- 3-tier flexible cost matching: New original / compatible replacement / refurbished tested options to align with your project quality standards and procurement budget;
- Tropical environment optimized solutions: All blowers pass aging tests to adapt to high-temperature, heavy-dust operating environments widely seen across African industrial & telecom sites;
- Verified global service track record: 15+ years serving clients in over 80 countries with mature technical matching, stable delivery and transparent procurement procedures.
5. Comprehensive Global Trade & Technical Support Services
Accepted Incoterms: FOB, CFR, CIF, EXW, FAS, FCA, DDP
Settlement Currencies: USD, EUR, HKD, GBP, CNY
Payment Methods: T/T, L/C, D/P, D/A, MoneyGram, Credit Card, PayPal, Cash
Multilingual Technical Support Team: English, Chinese, Spanish, Japanese, Portuguese, German, Arabic, French, Russian, Korean, Hindi, Italian
Send us your target fan model number, equipment application parameters, and brand requirements, our thermal engineering team will provide a fully customized technical quotation with matching datasheet support.
